## Introduction

The next step in math instruction is Trigonometric functions. These functions are very useful when trig functionality is need. These functions are more advanced than math instruction.

## Definition

The following is a list of the Trigonometric Functions in SLC 500:

## ASN - Arc Sine

#### Symbol #### Definition

Takes the arc sine of a number and stores the result (in radians) in the destination

• Carry (C), Always resets
• Overflow (V), Sets if overflow or an unsupported input is detected
• Zero (Z), Sets if the result is Zero; otherwise resets;
• Sign (S), Sets if result is negative; otherwise resets;

### ACS - Arc Cosine

#### Symbol #### Definition

Takes the arc cosine of a number and stores the result (in radians) in the destination

• Carry (C), Always resets
• Overflow (V), Sets if overflow or an unsupported input is detected
• Zero (Z), Sets if the result is Zero; otherwise resets;
• Sign (S), Always resets

### ATN - Arc Tangent

#### Symbol #### Definition

Takes the arc tangent of a number and stores the result (in radians) in the destination

• Carry (C), Always resets
• Overflow (V), Sets if overflow; otherwise resets
• Zero (Z), Sets if overflow or an unsupported input is detected
• Sign (S), Sets if result is negative; otherwise resets;

### COS - Cosine

#### Symbol #### Definition

Takes the cosine of a number and stores the result in the destination.

• Carry (C), Always resets
• Overflow (V), Sets if overflow; otherwise resets
• Zero (Z), Sets if overflow or an unsupported input is detected
• Sign (S), Sets if result is negative; otherwise resets;

### LN - Natural Log

#### Symbol #### Definition

Takes the natural log of value in the source and stores it in the destination

• Carry (C), Always resets
• Overflow (V), Sets if overflow; otherwise resets
• Zero (Z), Sets if overflow or an unsupported input is detected
• Sign (S), Sets if result is negative; otherwise resets;

### LOG - Log to the Base 10

#### Symbol #### Definition

Takes the log base 10 of the value in the source and stores the result in the destination

• Carry (C), Always resets
• Overflow (V), Sets if overflow; otherwise resets
• Zero (Z), Sets if overflow or an unsupported input is detected
• Sign (S), Sets if result is negative; otherwise resets;

### SIN - Sine

#### Symbol #### Definition

Takes the sine of a number and stores the result in the destination.

• Carry (C), Always resets
• Overflow (V), Sets if overflow; otherwise resets
• Zero (Z), Sets if overflow or an unsupported input is detected
• Sign (S), Sets if result is negative; otherwise resets;

### TAN - Tangent

#### Symbol #### Definition

Takes the tangent of a number and stores the result in the destination

• Carry (C), Always resets
• Overflow (V), Sets if overflow; otherwise resets
• Zero (Z), Sets if overflow or an unsupported input is detected
• Sign (S), Sets if result is negative; otherwise resets;
